750VDC 250a 4p MCCB DC Molded Case Circuit Breaker

Introducing the 750VDC 250a 4p MCCB DC Molded Case Circuit Breaker - Your Ultimate Solution for Circuit Protection

Are you tired of unreliable circuit breakers that lead to frequent system failures and costly downtime? Do you want a high-quality, robust, and efficient circuit breaker that can withstand even the toughest environments? Look no further than our 750VDC 250a 4p MCCB DC Molded Case Circuit Breaker!

At our manufacturing plant in China, we have spent years perfecting our circuit breakers to meet the needs of customers around the world. We understand the importance of reliable circuit protection and have invested in advanced technology and skilled personnel to produce the finest circuit breakers available on the market.

Our 750VDC 250a 4p MCCB DC Molded Case Circuit Breaker is the perfect example of our dedication to quality and excellence. This dynamic circuit breaker is designed to provide reliable and efficient protection to your electrical systems. It can handle 750 volts of direct current with a maximum current rating of 250 amperes.

One of the key features of our MCCB DC Molded Case Circuit Breaker is that it is constructed using high-quality materials, including durable molded case bodies made of premium-quality thermoplastics. This ensures that our circuit breakers can withstand even the harshest of environments, while also being lightweight and easy to install.

Another feature of our MCCB DC Molded Case Circuit Breaker is that it is compact and versatile, making it an excellent choice for a wide range of applications. Whether you need circuit protection for automotive, marine, or industrial applications, our circuit breaker is up to the task.

Our circuit breaker is also extremely easy to operate, with a simple ON/OFF switch mechanism that allows for quick and efficient switching. In addition, our circuit breaker is equipped with overload and short-circuit protection, ensuring that your systems stay safe and secure.

At our company, we take pride in providing the best customer service in the industry. We understand that our customers are looking for high-quality, reliable circuit breakers, and we are committed to delivering on this promise. We offer fast shipping and excellent customer support to ensure that our customers receive the best possible experience.

In conclusion, if you are looking for a high-quality, reliable, and efficient circuit breaker that can handle even the toughest of environments, look no further than our 750VDC 250a 4p MCCB DC Molded Case Circuit Breaker. Order now and experience the best in circuit protection technology - you won't be disappointed!

Main data of 750VDC 250a 4p mccb DC Molded Case Circuit Breake

Range:Compact

Product name:Compact MSX DC

Product or component type:Circuit breaker

Device short name:Compact MSX-PV 250F DC

Device application :Distribution

Poles description:4P

Protected poles description:4t

Network type:DC

[In] rated current:250A at 40 °C

[Ui] rated insulation voltage:750VDC conforming to IEC 60947-2

[Uimp] rated impulse withstand voltage:8kV conforming to IEC 60947-2

[Ue] rated operational voltage:750VDC conforming to IEC 60947-2

Breaking capacity code:F 36 kA 750VDC

Breaking capacity: 36 kA Icu at 250VDC 1P conforming to IEC 60947-2

36 kA Icu at 500VDC 2P conforming to IEC 60947-2

36 kA Icu at 750VDC 3P conforming to IEC 60947-2

36 kA Icu at 750VDC 4P conforming to IEC 60947-2

[Ics] rated service breaking capacity:36 kA at 750VDC conforming to IEC 60947-2

Suitability for isolation:Yes conforming to IEC 60947-2

Utilisation category:Category A

Trip unit name:TM-DC

Trip unit technology:Thermal-magnetic

Pollution degree:3 conforming to IEC 60947-2

Complementary of 750VDC 250a 4p mccb DC Molded Case Circuit Breake

Control type:Toggle

Mounting mode:Fixed

Mounting support:Backplate

Upside connection:Front

Downside connection:Front

Mechanical durability:5000 cycles

Electrical durability:1000 cycles 750VDC In conforming to IEC 60947-2 2000 cycles 750VDC In/2 conforming to IEC 60947-2

Connection pitch:45 mm

Local signalling;Positive contact indication

Protection type:L : for overload protection (thermal)

I : for short-circuit protection (magnetic)

Trip unit rating:250 A at 40 °C

Long time pick-up adjustment type Ir:Adjustable

Long time pick-up adjustment range:0.7...1 x In

Height:255 mm

Width:185 mm

Depth:110 mm

Environment of 750VDC 250a 4p mccb DC Molded Case Circuit Breake

IP degree of protection:IP20 conforming to IEC 60529

K degree of protection:IK07 conforming to EN 50102
